Bin Lift/Tipper
Specifically designed for use with 240L wheelie bins. This bin lifter makes light work of elevating product to where you need it!
- Industrial Bin Lifter & Material Handler (250kg Capacity)100% Aus/NZ Compliant | Maintenance-Free Linear Belt Drive. Automate your bulk ingredient handling and waste management with our premium commercial wheelie bin lifter. Engineered for continuous duty in heavy-duty environments, this unit safely handles loads up to 250kg.Powered by a world-class 1.1kW SEW-EURODRIVE gear unit paired with a linear toothed belt drive system, it delivers ultra-quiet, low maintenance operation. Whether tipping raw ingredients into a high factory hopper or discharging waste into a compactor, this unit optimizes your workflow while protecting your staff. Uncompromising Safety Features Designed to prioritize worker safety and meet stringent compliance codes: Integrated Safety Cage: Full physical enclosure protects operators from moving parts. Automatic Door Locking: Safety doors automatically lock when the cycle begins and remain sealed until the bin returns to the ground. Two-Button Activation at Height: High-level tipping operators require two-handed control, keeping the operator safely away from the mechanism. Aus/NZ Standards: Fully certified to meet strict Australian and New Zealand workplace safety regulations. Key Technical Specifications Load Capacity: Heavy-duty 250kg safe working load. Premium Drive System: 1.1kW SEW-Eurodrive electric motor for high-torque reliability.Toothed Belt Tech: Linear toothed belt ensures ultra-quiet lifting with zero chain maintenance or messy greasing.Cycle Time: Smooth, controlled 20-second lift-and-tip cycle to eliminate spills and structural wear.Power Options: Available in 415V Three-Phase for high-duty factory production or 240V Single-Phase for flexible facility deployment. Dual-Application Versatility Factory Processing Equipment: Seamlessly batch-load raw materials, food ingredients, chemical compounds, or product into mixers, hoppers, and production lines. Waste & Recycling Management: Effortlessly empty heavy waste, recycling, or organic matter into large skip bins and compactors. Custom Mounting & Engineering. Every facility layout is unique. We can build and configure each unit to slot perfectly into your existing infrastructure: Free-Standing: Mobile or floor-bolted units for dedicated tipping stations. Platform Mounted with Linear Travel: Track-mounted systems that travel sideways to service multiple skip bins, hoppers, or production lines. Custom Tipping Heights: Fully customizable frame heights engineered to match your specific processing equipment or skip sizes. Material Finishes, Premium Stainless Steel: Ultimate corrosion resistance and wash-down compatibility for food processing, pharmaceuticals, chemical labs, and hygiene-critical zones. Industrial Coated Steel: Rugged, cost-effective durability built for warehouses, general manufacturing, and construction sites.
- This Bin lifter is designed for fast efficient and safe handling of heavy bins which require elevating and tipping to empty the bin's contents at height. It can be supplied to order with variable height outfeed to suit your application. Get in touch via our contact page to find out more.
- Fixed base stand alone or platform mount with option of lateral linier travel.
- Stainless steel or powder coated steel options
- Flexible design changes available to suit your requirements
| Lifting Capacity | 250kg (551 pounds) |
|---|---|
| Power Supply | 230/400 delta/star |
| Tipping Height range (Ground to Tipping point) | 2m - 5m |
| Construction Material | 304 Stainless Steel or Powder Coated Mild Steel |
| Duty Cycle | 100% |
| KW | 1.1 |
| Drive Motor And Gear Box | SEW- EURODRIVE |
